Automatic or manual drainage pump model with removable filter for flat suction level of 2 to 3 mm, the different functions of this pump ensure versatility of installation configurations. Suitable for clean water with solid components up to 10 mm. Pump housing, fan, hood and grill are made of technopolymer. Motor housing, motor shaft, nuts and bolts made of stainless steel. Triple seal in oil bath. Asynchronous motor suitable for immersion with continuous operation. The stator is housed in a completely hermetically sealed casing of stainless steel. Rotor mounted between oversized self-lubricating ball bearings. Built-in thermal protection of bimetallic and permanently switched-on capicator. MAE Version. The height-adjustable probe makes it possible to adjust the suction level. This option broadens the installation options. The vertical press and electronic float make the pump suitable for installation in wells with small dimensions.

Flow rate: from 1 to 15 m3/h with a head up to 10 meters.
Liquid temperature range: from 0°C to 35°C.
Pumped liquid: turbid water without fibres.
Maximum immersion depth: 7 metres.
Installation: fixed or movable in vertical position.
Protection class: IP 68.
Insulation class: F
